| LED Display Color: | |
|---|---|
| Shell Type: | |
| Hardware: | |
| Battery: | |
| Language: | |
| Quantity: | |
ID226
WEBOWT
8226049(Red LED) / 822604A(Green LED)
ID226
Product Features
6-bit super large LED display with a word height of 33.4mm, available in red or green. Supports CPA 6000e certification accuracy and up to 200,000 display divisions.
Built-in switch power supply, supports wide voltage AC 85-264V power supply.
Built-in charging circuit, can be equipped with a 6V4.0AH lead-acid rechargeable battery.
Standard supports serial ports x 2: COM1 (RS232) + COM2 (RS485).
Standard supports MODBUS-RTU, continuous transmission, command input and output, SICS, and barcode scanner input.
Optional supports for add-ons
Relay output board
Ethernet communication board
Bluetooth communication board
WIFI communication board
Supports basic weighing function, X10 function, simple checkweighing and sorting function, counting function, and animal weighing function.
Supports Chinese printing function, capable of printing simple Chinese labels.
Installation method
ABS plastic shell (optional with round pipe bracket or square pipe bracket).
304 stainless steel dustproof housing (optional with desktop, round pipe bracket, or square pipe bracket).
Product Selection Configuration
| Indicator Model | Shell Type | Hardware | Battery | Printer | Language | Display |
| ID226 | 0 | A | 0 | 0 | 0 | 1 |
| ID226 | 0:Desktop SS1 housing 1:SLIM square column bracket 2:SLIM round pipe bracket 3:ABS housing round pipe bracket 4:Desktop SS2 housing 5:SS2 housing round pipe bracket 6:SS2 housing square column bracket 7:SS1 housing round pipe bracket 8:SS1 housing square column bracket 9:ABS housing square column bracket | A:RS232+RS485 1:RS232+RS485+Relay T:RS232+RS485+LAN W:RS232+RS485+WIFI Y:RS232+RS485+Bluetooth U:RS232+RS485+LAN+Relay V:RS232+RS485+WIFI+Relay X:RS232+RS485+Bluetooth+Relay | 0:None 1:NiMH battery (SLIM version) 2:Lead-acid battery | 0:None | 0:Standard application 1:Export version 2:Livestock scale without card reader,IP69K 3:Livestock scale with card reader,IP69K | 0:Red 1:Green |
Product Features
6-bit super large LED display with a word height of 33.4mm, available in red or green. Supports CPA 6000e certification accuracy and up to 200,000 display divisions.
Built-in switch power supply, supports wide voltage AC 85-264V power supply.
Built-in charging circuit, can be equipped with a 6V4.0AH lead-acid rechargeable battery.
Standard supports serial ports x 2: COM1 (RS232) + COM2 (RS485).
Standard supports MODBUS-RTU, continuous transmission, command input and output, SICS, and barcode scanner input.
Optional supports for add-ons
Relay output board
Ethernet communication board
Bluetooth communication board
WIFI communication board
Supports basic weighing function, X10 function, simple checkweighing and sorting function, counting function, and animal weighing function.
Supports Chinese printing function, capable of printing simple Chinese labels.
Installation method
ABS plastic shell (optional with round pipe bracket or square pipe bracket).
304 stainless steel dustproof housing (optional with desktop, round pipe bracket, or square pipe bracket).
Product Selection Configuration
| Indicator Model | Shell Type | Hardware | Battery | Printer | Language | Display |
| ID226 | 0 | A | 0 | 0 | 0 | 1 |
| ID226 | 0:Desktop SS1 housing 1:SLIM square column bracket 2:SLIM round pipe bracket 3:ABS housing round pipe bracket 4:Desktop SS2 housing 5:SS2 housing round pipe bracket 6:SS2 housing square column bracket 7:SS1 housing round pipe bracket 8:SS1 housing square column bracket 9:ABS housing square column bracket | A:RS232+RS485 1:RS232+RS485+Relay T:RS232+RS485+LAN W:RS232+RS485+WIFI Y:RS232+RS485+Bluetooth U:RS232+RS485+LAN+Relay V:RS232+RS485+WIFI+Relay X:RS232+RS485+Bluetooth+Relay | 0:None 1:NiMH battery (SLIM version) 2:Lead-acid battery | 0:None | 0:Standard application 1:Export version 2:Livestock scale without card reader,IP69K 3:Livestock scale with card reader,IP69K | 0:Red 1:Green |
