Suitable for platform scales, bagging scales, belt scales, hopper scales and process control weighing applications in chemical, pharmaceutical, food, lithium and other industries
6-bit LED display Supports analog scale input x 1, and up to 6 load cells Supports 60,000 display divisions Standard with serial port x 1 RS232/485 Standard supports MODBUS-RTU, PROFINET communication interface board (dual LAN ports, built-in switch, Siemens PLC) Options:
scale x 1 4-20 mA (16-bit precision DAC)
In x 4 / OC Out x 6
In x 4 / Relay Out x 6
Multiple calibration modes
Supports up to 2-point weight calibration
Calibration without weights
Remote calibration via PLC communication interface
Remote calibration via MODBUS-RTU communication interface
Supports applications
Basic weighing version
Material level weighing
Single-speed/dual-speed preset point fixed value control
Lower/upper limit level detection
Working power supply: DC 24VDC, the maximum power consumption of the complete machine is less than 6 W
6-bit LED display Supports scale x 1 analog scale input, and each channel supports up to 4 load cells input Accuracy according to the metrological approval (CPA) 3000e, with a maximum display resolution of 60,000 Standard with serial port x 1 RS232/485 Standard supports MODBUS-RTU Standard with In x 8 / OC Out x 8 or In x 8 / OC Out x 12 Applications
Basic weighing application with two-speed setpoint control (In x 8 / Out x 8 version)
Force application (In x 8 / Out x 8 version)
Bagging scale application (In x 8 / Out x 12 versions)
Working power supply:
DC 24VDC, the maximum power consumption of the complete machine is less than 6 W (In x 8 / Out x 8 version)
AC 85-264VAC, the maximum power consumption of the complete machine is less than 6 W (In x 8 / Out x 12 version)
