• Supports 1 analog scale platform connection, up to 12 load cells

• Measurement instrument type approval (CPA) 6000e certification accuracy, supporting up to 150000 display divisions

• Approved by European OIML and CE certification

• Standard configuration includes 2 serial ports RS232+RS2321485, or 2 serial ports RS232+RS485 Add an Ethernet port

• Standard configuration supports MODBUS-RTU and MODBUS-TCP (only supports network port versions)

• PLC communication interface options PROFIBUS-DP (Siemens PLC) CC ink (Mitsubishi PLC) PROFINET (dual port, built-in switch, Siemens PLC) EtherNetlP (dual port, built-in switch, Rockwell PLC, Delta PLC)

• 1 channel 4-20mA (16 bit precision DAC)

• 2 channels 4-20mA (16 bit precision DAC)

• I/O (Input/Output Options) 8 inputs and 12 transistor outputs 8 inputs and 12 relay outputs

• Multiple calibration modes Supports up to 5 weight calibration points Weightless calibration Remote calibration support application through PLC communication interface

• Basic weighing version/packaging version/weight inspection version/filling version/ingredient version

• The working power supply supports AC 85-264VAC or DC 24VDC, and the maximum power consumption of the entire machine is less than 6W;
