| Hardware: | |
|---|---|
| I/O Option: | |
| PLC I/F Option: | |
| Power Supply: | |
| Quantity: | |
ID511HC2000G (220VAC) / ID511HC2000D (24VDC)
WEBOWT
851101H(220VAC) / 851104N(24VDC)
ID511XX
Product Features
7-bit LED display
Supports 1 analog scale input, with a maximum of 12 load cells
Certification: CPA 6000e, division up to 150,000
Standard serial ports x 2 RS232 + RS232/485, or serial ports x 2 RS232 + RS485 with one LAN port
Standard supports MODBUS-RTU, MODBUS-TCP (only supported by the ethernet version)
Optional PLC communication interface
PROFIBUS-DP (Siemens PLC) • CC-link (Mitsubishi PLC)
PROFINET (dual LAN ports, built-in switch, Siemens PLC)
EtherNet/IP (dual LAN ports, built-in switch, Rockwell PLC, Delta PLC)
scale x 1 4-20 mA (16-bit precision DAC) • scales x 2 4-20 mA (16-bit precision DAC)
Optional I/O (input/output)
In x 8 / OC Out x 12
Multiple calibration modes
Supports up to 5-point weight calibration • Calibration without weight
Remote calibration via PLC communication interface
Application supports
Basic weighing version • Lower/upper limit level detection
Supports dual-speed preset point control and 8 simple comparison outputs
Built-in load cell safety barrier supports direct connection to scale platforms in Zone 1 and Zone 2
Working power supply
DC 24VDC, maximum power consumption of the complete machine is less than 6 W
Product Selection Configuration
| Indicator Mode Number | Shell Type | Hardware | I/OOption | PLCInterface | Application Sub-ltems | Language | PowerSupply | ||
| ID511 | P | J | 1 | 0 | 1 | 0 | A | ||
| ID511 | P:Panel type D:DIN Type | J:Serial ports x 2(RS232 +RS232/485),high precision version | 0:None 1:In x 8/OC Out x 12 2:In x 8/Relay Out x12 | 0:None A:Scale x 1 4-20mA output B:Scales x 2 4-20mA output C:CC-LINK D:DeviceNet E:EtherNet/IP F:PROFINET G:EtherNet/IP+scale x 1 4-20mA H:PROFINET+scale x 1 4-20mA P:PROFIBUS-DP R:ABRIO (DH+) T:EtherCAT U:EtherCAT+scae x 1 4-20mA V:PROFIBUS-DP+scale x 1 4-20mA | 0:Basic application | 0:Chinese 1:English | A:110/220VAC (no power cable) D:24VDC (no power cable) | ||
| K:LAN port and serial ports x 2 (LAN+RS232+RS485), high precision version | 0:None | ||||||||
Product Features
7-bit LED display
Supports 1 analog scale input, with a maximum of 12 load cells
Certification: CPA 6000e, division up to 150,000
Standard serial ports x 2 RS232 + RS232/485, or serial ports x 2 RS232 + RS485 with one LAN port
Standard supports MODBUS-RTU, MODBUS-TCP (only supported by the ethernet version)
Optional PLC communication interface
PROFIBUS-DP (Siemens PLC) • CC-link (Mitsubishi PLC)
PROFINET (dual LAN ports, built-in switch, Siemens PLC)
EtherNet/IP (dual LAN ports, built-in switch, Rockwell PLC, Delta PLC)
scale x 1 4-20 mA (16-bit precision DAC) • scales x 2 4-20 mA (16-bit precision DAC)
Optional I/O (input/output)
In x 8 / OC Out x 12
Multiple calibration modes
Supports up to 5-point weight calibration • Calibration without weight
Remote calibration via PLC communication interface
Application supports
Basic weighing version • Lower/upper limit level detection
Supports dual-speed preset point control and 8 simple comparison outputs
Built-in load cell safety barrier supports direct connection to scale platforms in Zone 1 and Zone 2
Working power supply
DC 24VDC, maximum power consumption of the complete machine is less than 6 W
Product Selection Configuration
| Indicator Mode Number | Shell Type | Hardware | I/OOption | PLCInterface | Application Sub-ltems | Language | PowerSupply | ||
| ID511 | P | J | 1 | 0 | 1 | 0 | A | ||
| ID511 | P:Panel type D:DIN Type | J:Serial ports x 2(RS232 +RS232/485),high precision version | 0:None 1:In x 8/OC Out x 12 2:In x 8/Relay Out x12 | 0:None A:Scale x 1 4-20mA output B:Scales x 2 4-20mA output C:CC-LINK D:DeviceNet E:EtherNet/IP F:PROFINET G:EtherNet/IP+scale x 1 4-20mA H:PROFINET+scale x 1 4-20mA P:PROFIBUS-DP R:ABRIO (DH+) T:EtherCAT U:EtherCAT+scae x 1 4-20mA V:PROFIBUS-DP+scale x 1 4-20mA | 0:Basic application | 0:Chinese 1:English | A:110/220VAC (no power cable) D:24VDC (no power cable) | ||
| K:LAN port and serial ports x 2 (LAN+RS232+RS485), high precision version | 0:None | ||||||||
